Polaris Electro-Optics Secures $50M Series B to Scale FenGlass Platform

Led by Walden Catalyst Ventures, the round funds FenGlass production for AI optical interconnects.

9/16/2026
Yassine Benadou
Back to News

Polaris Electro-Optics, Inc. has announced a $50 million Series B funding round to advance its FenGlass electro-optic modulator platform into production. The investment was led by Walden Catalyst Ventures and included new investors Socratic Partners, Cambium Capital, Knollwood, and Hudson River Trading. Existing backers Koch Disruptive Technologies, M Ventures, Rhapsody Venture Partners, Buff Gold Ventures, and Blue Sky Capital also participated, and Andy Kau of Walden Catalyst Ventures will join the board.


Addressing AI Infrastructure Bottlenecks

As artificial intelligence workloads continue to grow in the agentic era, data movement has become a critical bottleneck in AI infrastructure. Networks face severe bandwidth constraints while energy consumption per bit remains unsustainable for large scale deployments. Hyperscalers, neoclouds, and infrastructure providers are therefore moving toward 400 Gbps per lane and beyond for scale-up, scale-out, scale-across, and data center interconnect applications.

FenGlass Platform Advantages

The FenGlass platform removes the trade-off between manufacturability, reliability, and bandwidth that has limited other next generation modulator technologies. It uses a proprietary ferroelectric nematic glass with a strong Pockels effect, integrated directly onto finished silicon photonic wafers after they leave the foundry. This approach requires standard processes and no poling, enabling modulators that achieve 400 Gbps per lane with sub-volt drive voltages in a compact footprint.

Leadership Perspective

Chief Executive Officer Morten Nissov stated that the industry faces both speed and manufacturing challenges at the same time, while existing platforms typically solve only one. He emphasized that FenGlass enables 400G per lane and beyond while remaining within a standard CMOS silicon photonics flow. According to Nissov, the new financing supports the company's move from a proven device to large scale commercial deployment.

Validation and Commercial Roadmap

Polaris has demonstrated and independently verified 400 Gbps per lane modulation with FenGlass, completed Telcordia reliability tests, and validated compatibility with standard solder reflow. These milestones are critical for next generation optical interconnect applications that rely on flip-chip, 2.5D, and 3D packaging. Because FenGlass is an engineered material, its electro-optic response can be tuned across product generations from 200G per lane to 400G and toward 800G.

Investor Confidence

Walden Catalyst Ventures Partner Andy Kau noted that new electro-optic materials have often worked in the lab but failed in the fab. He said Polaris convinced the firm because FenGlass is applied to a finished silicon photonics wafer using processes that contract manufacturers already run. Kau added that performance and reliability are table stakes, while ease of integration and the path to scale drove the investment decision.

Commercial Partnerships and Use of Funds

Polaris is partnering with optical module makers, hyperscalers, and major cloud infrastructure providers to enable solutions across pluggable modules, near-packaged optics, co-packaged optics, and coherent scale-across architectures. The company plans its first product launch for 2027 and will use the proceeds for portfolio expansion, volume scale-up, product tapeouts, qualification, and engineering hiring. Polaris operates from Carlsbad, California and Boulder, Colorado after being founded in 2021 as a spinout of the University of Colorado Boulder.


With this new capital, Polaris Electro-Optics is positioned to move its FenGlass technology from demonstrated performance to large scale commercial deployment. The company's approach addresses both manufacturing feasibility and the escalating bandwidth demands of AI infrastructure. A first product launch targeted for 2027 signals a concrete step toward next generation optical interconnects at 400 Gbps per lane and beyond.
